EXCCD Series C-mount USB2.0 CCD Camera

EXCCD Series C-mount USB2.0 CCD Camera

USB2.0, intelligent image processing, superior color restoration

Features


  • Standard C-Mount camera with SONY ExView 0.3M~1.4M sensors
  • USB2.0 interface ensuring high speed data transmission
  • Ultra-Fine color engine with perfect color reproduction capability
  • With advanced video & image processing application ToupView
  • Providing Windows/Linux/Mac OS multiple platforms SDK
  • Native C/C++, C#/VB.NET, DirectShow, Twain Control API

Tags: CCD CamerasC-mount CamerasUSB2.0 Cameras

Request a Quote?


Get Quote Live chat Email Phone

Standard C-Mount
USB2.0
SONY CCD
Ultra-Fine color engine

EXCCD is an ExView HAD CCD camera and it adopts Sony ExView HAD CCD sensor as the image-picking device. Sony ExView HAD CCD is a CCD that drastically improves light efficiency by including near infrared light region as a basic structure of HAD (Hole-Accumulation-Diode) sensor. Jingtong uses EXCCD for simplicity. USB2.0 is used as the data transfer interface.

EXCCD comes with advanced video & image processing application; Providing Windows/Linux/OSX multiple platform SDK; Native C/C++, C#/VB.NET, DirectShow, Twain Control API;

The EXCCD can be widely used in low light environment and microscope fluorescence image capture and analysis.

EXCCD Series

Dimension of EXCCD

The EXCCD body, made from tough, zinc alloy, ensures a heavy duty, workhorse solution. The camera is designed with a high quality IR-CUT to protect the camera sensor. No moving parts included. This design ensures a rugged, robust solution with an increased lifespan when compared to other industrial camera solutions.

Dimension of EXCCD Series

Dimension of EXCCD

Extension of EXCCD with Microscope or Telescope Adapter

Application


C-mount Camera

Machine vision; Medical imaging;
Semiconductor equipment; Test instruments;
Document scanners; 2D barcode readers;
Web camera and security video;
Microscope imaging;

Microscope Camera

Extension of EXCCD Series with Microscope or Telescope Adapter

Telescope Camera

Order Code

Sensor & Size(mm)

Pixel(μm)

G Sensitivity

Dark Signal

FPS/Resolution

Binning

Exposure

EXCCD01400KPA
TP801400A

1.4M/ICX285AQ(C)
2/3“ (8.77x6.60)

6.45x6.45

1240mv with 1/30s
10mv with 1/30s

[email protected]

1x1

0.12ms~240s

EXCCD01400KMA
TM801400A

1.4M/ICX285AL(M)
2/3“ (8.77x6.60)

6.45x6.45

1300mv with 1/30s

11mv with 1/30s

[email protected]

1x1

0.12ms~240s

EXCCD00440KMA
TM800440A

0.44M/ICX829AL(M)
1/2''(6.43x4.80)

8.6X8.3

2800mv with 1/30s

2mv with 1/30s

[email protected]

1X1

0.20ms~3600s

EXCCD00300KMA
TM800300A

0.3M ICX618AL(M)
1/4“ (3.58x2.69)

5.6x5.6

1200mv with 1/30s

4mv with 1/30s

[email protected]

1x1

0.06ms~40s,

C: Color; M: Monochrome;

Other Specification for EXCCD Cameras

Spectral Range

380-650nm (with IR-cut Filter)

White Balance

ROI White Balance/ Manual Temp Tint Adjustment /NA for Monochromatic Sensor

Color Technique

Ultra-FineTM Color Engine /NA for Monochromatic Sensor

Capture/Control API

Native C/C++, C#/VB.NET, DirectShow, Twain and Labview

Recording System

Still Picture and Movie

Cooling System*

Natural

Operating Environment

Operating Temperature(in Centidegree)

-10~ 50

Storage Temperature(in Centidegree)

-20~ 60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB Port

Software Environment

Operating System

Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit)

OSx(Mac OS X)

Linux

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or Higher

Memory:2GB or More

USB Port:USB2.0 High-speed Port

Display:17” or Larger

CD-ROM

Sample Images Captured witd EXCCD Camera(EXCCD01400KPA)

tde microscope slide images are captured witd TPS001015 slide package and witd EXCCD01400KPAcamera.

Typical dicot root,ranunculus mature root csMonocot root(zea mays)
Dicot stem deliantdus older stemMonocot stem (zea mays stem c.s.)
Dicot leaf heliantdus leaf c.s.Monocot leaf zea mays c.s.
CladymonasLeaf of pine needle
Human Cell Mucus Membrane (smear)Frog Epidermic Cell (section)
Dog squamous Epitdeblium (whole mount)Paramecium (whole mount)
Hydra (cross section)Eartdworm (crosssection)
Daphina (whole mount)

Packing Information for EXCCD

Standard Camera Packing List

A

Carton L:52cm W:32cm H:33cm (20pcs, 12~17Kg/ carton), not shown in the photo

B

Gift box L:15cm W:15cm H:10cm (0.67~0.80Kg/ box)

C

EXCCD series USB2.0 C-Mount camera

D

High-speed USB2.0 A male to B male gold-plated connectors cable /2.0m

E

CD (Driver & utilities software, Ø12cm)

Optional Accessory

F

Adjustable lens adapter

C-mount to Dia.23.2mm eyepiece tube
(Please choose 1 of them for your microscope)

108001/AMA037
108002/AMA050
108003/AMA075

C-Mount to Dia.31.75mm eyepiece tube
(Please choose 1 of them for your telescope)

108008/ATA037
108009/ATA050
108010/ATA075

G

Fixed lens Adapter

C-mount to Dia.23.2mm eyepiece tube
(Please choose 1 of them for your microscope)

108005/FMA037
108006/FMA050
108007/FMA075

C-mount to Dia.31.75mm eyepiece tube
(Please choose 1 of them for your telescope)

108011/FTA037
108012/FTA050
108013/FTA075

Note: For F and G optional items, please specify your camera type(C-mount, microscope camera or telescope camera), Jingtong engineer will help you to determine the right microscope or telescope camera adapter for your application;

H

108015(Dia.23.2mm to 30.0mm Ring)/Adapter rings for 30mm eyepiece tube

I

108016(Dia.23.2mm to 30.5mm Ring)/ Adapter rings for 30.5mm eyepiece tube

J

108017(Dia.23.2mm to 31.75mm Ring)/ Adapter rings for 31.75mm eyepiece tube

K

Calibration kit

106011/TS-M1(X=0.01mm/100Div.);
106012/TS-M2(X,Y=0.01mm/100Div.);
106013/TS-M7(X=0.01mm/100Div., 0.10mm/100Div.)
