DM350-C HDMI Digital Eyepiece Camera

DM350-C

practical operation. HDMI 1080i

Features


  • Special manual focus on the top of camera to extend working distance
  • HDMI 1080i 60fps preview 720P 30fps record
  • Multi modes are provided on exposure and white balance
  • User defined crop selected cross line
  • TF card slot Maximum support 64G
  • 4X digital zoom

Tags: Digital Eyepiece CamerasHDMI CamerasCMOS Cameras

Request a Quote?


Get Quote Live chat Email Phone

TF card
64G
manual focus
HDMI 1080i
4X digital zoom
Aptina CMOS
  • Special manual focus on the top of camera to extend working distance
  • HDMI 1080i 60fps preview 720P 30fps record
  • Multi modes are provided on exposure and white balance
  • User defined crop selected cross line
  • TF card slot Maximum support 64G
  • 4X digital zoom

DM350-CDM350-C's Back Panel

DM350-C and its Back Panel

Different view of DM350-CDifferent view of DM350-C

Different views of DM350-C

Different view of DM350-CDifferent view of DM350-C

Different views of DM350-C

DM350-C and its Microscope

DM350-C and its Microscope

Hardware configuration

Image Sensor

Aptina AR0330 CMOS Sensor

Expose mode

Rolling shutter

Maximum Resolution

2304 x 1536 (3,538,944 pixels)

Sensor Optical Format

1/3'' (5.07mm(H) x 3.38mm(V), Diagonal 6.09mm)

Pixel Size

2.2μm x 2.2μm

Dynamic Range

69.5dB

SNR(Signal Noise Ratio)

39dB

Spectral Characteristics

380~650nm

Exposure Capability

Real-time auto, Single auto, Manual adjustment

White Balance

Real-time auto, Single auto, Manual adjust R G B seperately

Display(preview) resolution

HDMI:1920X1080i60,1920X1080P30,1280x720P60,640x480P60(Auto fit-to-fill displayer)

USB:[email protected],[email protected](Optional to display)

Record format

Snapshot

Picture Format:JPG

Resolution:

HDMI: 2304 x 1536,2304 x 1296,1920x1080,1280x720,800x480

USB: 1920x1080,1280x720,800x480

Record

Video Format:MOV

Resolution:

HDMI:[email protected], [email protected]

USB:[email protected], [email protected], [email protected]

Record Route

HDMI:TF card(Maximum support 64G) USB:PC

Software Environment

Power supply

HDMI: Direct current 5.0V, power plug, (maximum current 1A)

USB:USB port of PC or laptop (no need other power supply)

Displayer

Recommend 16:9 , at least 1080P HD displayer

Operating Environment

Operating Temperature

0℃~40℃

Storage Temperature

-20℃~60℃

Operating Humidity

30~60%RH

Storage Humidity

10~80%RH

Sample Photos Captured with DM350-C

Dog Skeletal Muscle l.s. & c.s.

4X Objective

10X Objective

40X Objective

54. Simple squamous epithelium sec.

4X Objective

10X Objective

40X Objective

Dog Ileum c.s.

4X Objective

10X Objective

40X Objective
