VM3000 Series Inverted Scientific Research Grade Metallurgical Microscope with Polarized Device
6V30W / 12V50W Halogen lamp with brightness control
Features
- Adopted excellent optical system, equipped with excellent optical performance
- With wide field eyepieces and plan achromatic objectives, the field of view is wide and clear
- Coaxial coarse/fine focus system, with tension adjustable, minimum division of fine focusing: 2μm
Tags: Compound MicroscopesMetallurgical Microscopes
Request a Quote?
Get Quote Live chat Email Phone
242mm x 200mm
6V30W / 12V50W
yellow ,green, blue
VM3000 Series Inverted metallurgical microscope is equipped excellent UIS optical system and modularization function design so that update system expediently and achieved polarization, dark field observation. Compact and steady main frame body is embodiment for the shock resistance. The ideal ergonomic design is adopted in this unit and has easier operation and wider space. This is ideal optical instrument for micro observation in metallographic structure and surface morphology. It is suitable for research in metallography, mineralogy, precision engineering, etc.
The gemel mode binocular is inclined 45°. The operator cervix and shoulder are released from tired in period of time keeping bow or head-up. The eyepatch can be added.
The circular chromeplate substage is located in the center of mechanical stage so that enable rotate the specimen in the polarization observation. The abnormity observation window is suit for different size specimen.
Equip high quality bright and dark field objectives and dark field illumination device. Avoid the stray light of illumination system and improve the image quality in the dark field.
The photographic observation output is setting up on the back of main body frame, so that the accessories of camera don’t cause interference to eyepiece observation. Microphotography in 100% light flux, suits for low illuminance microphotography.
VM3000 Series
Head & Mechanical Stage of VM3000 Series
Illumination System & Photographt Unit of VM3000 Series
Digital Camera Photography
Polarized Observe
Dark Type Observe
Bright Type Observe
Item | VM3000(Equipped with bright field objectives) | VM3000BD(Equipped with bright & dark field objectives) |
|---|---|---|
Objective | PL L10X/0.25 (Work distance)：5 mm | PL L5X/0.12 BD (Work distance)：8.05mm |
PL L20X/0.40 (Work distance)：8.80 mm | PL L10X/0.25 BD (Work distance)：7.86 mm | |
PL L50X/0.70 (Work distance)：3.68 mm | PL L20X/0.40 BD (Work distance)：7.23mm | |
PL L100X/0.85（Dry） (Work distance)：0.40 mm | PL L50X/0.70 BD (Work distance)：2.50mm | |
Magnification | 100X~1000X | 50X~500X |
Specification for VM3000 Series | |
|---|---|
Eyepiece | WF10X(Φ22mm) |
Eyepiece Tube | inclined 45°, interpupillary distance: 53~75mm |
Focus System | Coaxial coarse/fine focus, with tension adjustable，minimum division of fine focusing is 2μm |
Nosepiece | Quintuple (Backward ball bearing inner locating) |
Stage | Mechanical Stage (Size: 242mm x 200mm, Move range: 30mm x 30mm) |
Rotundity and rotatable stage size: maximal measurement is Ф130mm and minimal clear aperture is less then Ф20mm. | |
Illumination System | 6V30W halogen and brightness enable control., use in VM3000 |
12V50W halogen and brightness enable control., use in VM3000BD | |
Integrated field diaphragm , aperture diaphragm and puller type polarizer. | |
Equipped with frosted glass and yellow ,green and blue filters | |
Accessories for VM3000 Series | ||
|---|---|---|
Eyepiece | Dividing Eyepiece 10X (Φ22mm) | |
Objective | Equipped with bright field objectives | PL L5X/0.12 (Work distance)：26.1 mm |
PL L40X/0.60 (Work distance)：3.98 mm | ||
PL L60X/0.70 (Work distance)：2.08mm | ||
PL L80X/0.80 (Work distance)：1.28 mm | ||
Equipped with bright & dark field objectives | PL L40X/0.60 BD (Work distance)：3.00 mm | |
PL L60X/0.7 BD (Work distance)：1.65mm | ||
PL L80X/0.80 BD (Work distance)：0.80mm | ||
PL L100X/0.85 BD (Work distance)：0.4 mm | ||
CCD Adapter | 0.5X | |
1X | ||
0.5X (with dividing 0.1mm/Div) | ||
Camera | DV-1 Video output 380/520 TV line USB output 0.42 M pixel | |
DV-2 With USB output, 1.3M,2.0M,3.0M pixel | ||
DV-3 With Video output 380/520 TV line | ||
Digital camera adapter | CANON (EF) NIKON(F) | |
