Hardware Configuration |
|---|
Image Sensor | SONY IMX226 CMOS Sensor |
Expose mode | Rolling shutter |
Maximum Resolution | 4000x3000 (12,000,000 pixels) |
Sensor Optical Format | 1/1.7'' |
Pixel Size | 1.85μm x 1.85μm |
Dynamic Range | ＞80dB |
SNRmax | ≥50dB |
Spectral Characteristics | 380～650nm |
Exposure Capability | Real-time auto, Single auto, Manual adjustment |
White Balance | Real-time auto, Single auto, Manual adjustment R B seperately |
Record format | Snapshot Picture Format：JPG Resolution：4000x3000 Record Video Format：MOV Resolution：4000X3000@15FPS, 4096X2160@25FPS,3840x2160@25FPS，2592x1944@25FPS |
Software Environment |
|---|
Windows System Demand | Microsoft® Windows® XP / 7 / 8 /8.1/10(32 & 64 bit) |
CPU: i7 quad core 3.0GHz or higher |
Memory ：8G or more |
At least 10 GB available hard disk space |
Wireless network card (support 5G WiFi IEE802.11ac） |
iOS System Demand | iPhone X/ 8/ 8 Plus/7/ 7 Plus/6s/6s Plus/ 6/6 Plus iPad Pro (12.9-inch 2nd generation)/（12.9-inch 1st generation）/（10.5-inch）/（9.7-inch） iPad Air 2/iPad mini 4 and other new devices that support the 5G WiFi (11ac) protocol |
iOS11.0 or higher |
Android5.0 or higher | Android5.0 or higher |
CPU: dual-core 1.7GHz or higher |
RAM memory：2G or more |
Storage ROM：suggest 8G or larger |
*Please confirm smart devices hardware must support 5G WiFi (11ac) protocol,otherwise it will not acquire image under microscope camera properly.
