Hardware Configuration |
|---|
Image Sensor | SONY IMX334 CMOS Sensor |
Expose mode | Rolling shutter |
Maximum Resolution | 3840x2160 (8,294,400 pixels) |
Sensor Optical Format | 1/1.8'' |
Pixel Size | 2.0μm x 2.0μm |
Dynamic Range | 72db(non-HDR mode) |
SNRmax | <0.64lx |
Spectral Characteristics | 380～650nm |
Exposure Capability | Automatic and manual |
White Balance | Automatic and manual |
Record format | Snapshot Picture Format：JPG,BMP,PNG,TIFF,PDF Resolution：3840x2160 ,2592x1944,1920x1080,1024x768,640x480 Record Video Format：MJPG format AVI file Resolution：3840x2160 ,2592x1944,1920x1080,1024x768,640x480 |
Micro USB interface | Wired picture USB2.0 DC 5.0V 500mA |
Camera Interface | C Port |
Wireless Parameter |
|---|
Standard | 2.4G: IEEE 802.11n |
5G: IEEE 802.11n/ac |
Operating Frequency Range | 2.4G: 2.400-2.4835GHz |
5G: 5.180-5.825GHz |
Software Environment |
|---|
Windows System Demand | Microsoft® Windows® XP / 7 / 8 /8.1/10(32 & 64 bit) |
CPU: Dual-core 3.0 GHz or more CPU |
Memory ：4G or more |
At least 10 GB available hard disk space |
Wireless network card (support IEEE 802.11n/ac） |
iOS System Demand | iPhone X/ 8/ 8 Plus/7/ 7 Plus/6s/6s Plus/ 6/6 Plus iPad Pro (12.9-inch 2nd generation)/（12.9-inch 1st generation）/（10.5-inch）/（9.7-inch） iPad Air 2/iPad mini 4 |
iOS11.0 or higher |
Android5.0 or higher | Android5.0 or higher |
CPU: dual-core 1.7GHz or higher |
RAM memory：1G or more |
Storage ROM：suggest 8G or larger |
*In the wireless working status, you can switch to 2.4G WiFi or 5G WiFi mode. Please confirm that the hardware of the smart device supports 5G WiFi IEE 802.11ac/n protocol; otherwise, images cannot be obtained normally in 5G WiFi mode.
