Hardware Configuration |
|---|
Image Sensor | APTINA AR0521 CMOS(colorful) |
Expose mode | Rolling shutter |
Maximum Resolution | 2592x1944 (5,038,848 pixels) |
Sensor Optical Format | 1/2.5'' |
Pixel Size | 2.2μm x 2.2μm(BSI) |
Dynamic Range | 74.3dB Linear, more than 96 dB (Interleaved) |
SNRmax | 40dB |
Spectral Characteristics | 380～650nm |
Exposure Capability | 3.9ms-320ms, Automatic and manual |
White Balance | Real-time auto, Single auto, Manual adjustment |
Maximum Transmission Frame Rate(USB mode) | 30FPS@2592x1944, 1920x1080, 1024x768, 640x480 |
Maximum Transmission Frame Rate(Wifi mode) | 30FPS@2592x1944, 1920x1080, 1024x768, 640x480 |
Record format | Snapshot Picture Format：JPG, BMP,PNG,TIFF,PDF Resolution：2592x1944, 1920x1080, 1024x768, 640x480 Record Video Format：MJPG format AVI file Resolution：1920x1080, 1024x768, 640x480 |
Micro USB interface | Wired picture USB2.0 DC5.0V 500mA |
Camera Interface | C Port |
Wireless Parameter |
|---|
Standard | 2.4G: IEEE 802.11n |
5G: IEEE 802.11n/ac |
Operating Frequency Range | 2.4G: 2.400-2.4835GHz |
5G: 5.180-5.825GHz |
Software Environment |
|---|
Windows System Demand | Microsoft® Windows® XP / 7 / 8 /8.1/10(32 & 64 bit) |
CPU: Dual-core 3.0 GHz or more CPU |
Memory ：4G or more |
At least 10 GB available hard disk space |
Wireless network card(support IEEE 802.11n/ac） |
iOS System Demand | iPhone X/ 8/ 8 Plus/7/ 7 Plus/6s/6s Plus/ 6/6 Plus iPad Pro (12.9-inch 2nd generation)/（12.9-inch 1st generation）/（10.5-inch）/（9.7-inch） iPad Air 2/iPad mini 4 |
iOS11.0 or higher |
Android5.0 or higher | Android5.0 or higher |
CPU: dual-core 1.7GHz or higher |
RAM memory：1G or more |
Storage ROM：suggest 8G or larger |
*In the wireless working status, you can switch to 2.4G WiFi or 5G WiFi mode. Please confirm that the hardware of the smart device supports 5G WiFi IEE 802.11ac/n protocol; otherwise, images cannot be obtained normally in 5G WiFi mode.
