Hardware configuration |
|---|
Image Sensor | Omnivision OV5640 CMOS(colorful) |
Expose mode | Rolling shut1er |
Maximum Resolution | 2592 x 1944 (5038848 pixels) |
Sensor Optical Format | 1/4" |
Pixel Size | 1.4μm x 1.4μm |
Dynamic Range | 68dB |
ADC | 12-bit. 8-Bit R.G.B to PC |
SNR ( Signal Noise Ratio ) | 38.1dB |
Spectral Characteristics | 380-650nm |
Binning Modes | 2x2 |
Exposure Capability | 3.9ms - 320ms. Automatic and manual |
White Balance | Automatic and manual |
Software Interface | DirectShow |
Maximum Transmission Frame Rate (USB mode ) | 10FPS 2592x1944 15FPS 1920x1080 f 1280x1024 f 1280x720 30FPS 1280x9601024x768800x600640x480 |
Maximum Transmission Frame Rate (WiFi mode) | 10FPS 2592x1944 15FPS 1920x1080 f 1280x1024 f 1280x720 30FPS 1280x9601024x768800x600640x480 |
Record format | Snapshot Picture Format：JPG,BMP,PNG,TIFF,PDF Resolution：2592x1944, 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 640x480 Record Video Format：MJPG format AVI file Resolution：1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 640x480 |
Comprehensive resolution (when display on 21 inch 16:9 screen) | 23x , 95x ( this data is based on preview resolution is 640x480 with decompression zoom and the picture is display to adapt to screen） |
Interface Parameter |
|---|
Wired picture / Charger interface | Micro USB interface USB2.0 DC5.0V 500mA（wired picture）DC5.0V 2A（when charging power) |
Wireless Parameter/Power Parameter |
|---|
Standard | 802.11a/b/g/n |
Operating Frequency Range | 2.400 ~ 2.4835GHz ( subject to local regulations) |
Available Channels | 802.11n 20MHz/40MHz |
802.11b/g |
USA, Canada (FCC):11 channels (2.412GHz~2.462GHz) |
Europe (CE): 13 channels (2.412GHz~2.472GHz) |
Japan (TELEC): 14 channels (2.412GHz~2.4835GHz) |
Data Rate | 802.11n: up to 300Mbps 2T2R |
802.11b: up to 11Mbps |
802.11g: up to 54Mbps |
Transmission Power | 11n HT40 MCS7 : +16dBm +/-1.5dBm |
Receiving Sensitivity | -70 dBm@10% PER at HT40 MCS7 |
-76 dBm@10% PER at 54Mpbs |
-88 dBm@10% PER at 11Mpbs |
The amount of available displayers | 10@640x480 |
8@800x600 |
6@1024x768 |
5@1280x720 |
5@1280x960 |
4@1920x1080 |
3@2592x1944 |
The wireless work instructions | When there has not WiFi，LED lamp turn off |
When WiFi is opened but do not connect，LED is always lighting |
When WiFi is connected, LED flashes at the beginning and stay turn on afterward |
When WiFi is connected，LED flashes，about once per second，The greater the amount of data the faster it flashes, and it is about 10 times per second |
Build in battery | Rechargeable lithium coin cells 700mAh |
Continuous working period | About 90 minute |
Charging time | About 1.5 hours |
Charge lamp,(internal battery) | When battery is charging：the light will be always red |
When battery is fully charged: the light will be always green |
Power lamp,(internal battery) | High battery：power lamp will be always green |
Low battery：power lamp will be always red |
Charge Cycle | 500 times@50% power |
Power-up | Wireless ：internal battery |
power-up 、charge：DC 5V 2A adapter |
