VMF30A Biological & Medical Treatment Fluorescent Microscope with Up & Down Light Source
Optional camera observation unit / phase contract unit
Features
- With wide field eyepieces and infinity plan achromatic objectives, the field of view is widely and clear
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm
- 20W 6V halogen lamp with electronic dimmer
Tags: Compound MicroscopesFluorescence Microscope
Request a Quote?
Get Quote Live chat Email Phone
VMF30A Epifluorescent microscope is used for fluorescence microscopy and transmitted field observation. It is equipped with infinity plan
achromatic objectives and wide field eyepieces, have clear picture and wide view field. It is the ideal instrument in biology, cytology, oncology,
genetics, immunology etc. It also can be used in scientific research, universities, medical treatment, epidemic prevention etc.
Trinocular can be connected to the camera. 10X wide field plan eyepiece, field Φ20mm, can provide an expanse and smooth space for observation.
Turnplate reflected fluorescence observation set provides four fluorescence filter system as UV, V, B and G. This kind of frame can make it switch fleetly between each fluorescence system. 100W mercury lamp can provide ample illumiantion for fluorescence observation. Built-in field diaphragm, center adjustable, is good for the control of field range.
The illumination system with 6V 30W halogen lamp (brightness adjustable) can provide clear and bright image for light field observation, but also for phase contrast observation. The system also includes the collector with field diaphragm.
By adding the appurtenance of phase contrast unit and camera unit, it can spread to mainfold modes for observation that satisfy the need to different research work.
VMF30A
Reflected Fluorescence & Transmitted Illumination System of VMF30A
Digital Camera Photo
Fluorescence Observe
Phase Observe
Diagram of VMF30A
Dimension of VMF30A
Specification for VMF30A | |
|---|---|
Eyepiece | WF 10X (Φ20mm) |
Eyepiece Tube | Trinocular, inclined 30° |
Objective | Infinity Plan Achromatic Objectives PL 4X/0.10 |
Infinity Plan Achromatic Objectives PL 10X/0.25 | |
Infinity Plan Achromatic Objectives PL 40X/0.65 (Spring) | |
Infinity Plan Achromatic Objectives PL 100X/1.25 (Spring、Oil) | |
Focus System | Coaxial coarse/fine focus system, with tension adjustable and up stop, minimum division of fine focusing is 2.0μm |
Nosepiece | Quadruple (Backward ball bearing inner locating) |
Working Stage | Double layer mechanical (Size:210mmX140mm,moving range:75mmX50mm) |
Abbe Condenser | N.A.1.25 Rack & pinion adjustable |
Filter | Blue filter |
Frosted filter | |
Collector | For Halogen Lamp |
Light Source | 6V 20W Halogen Lamp, adjustable brightness |
Reflected Fluorescence System | Mercury Lamp House 100W/DC |
Power Supply Unit: AV: 110V or 220V | |
Fluorescence filter system B Exciton Wavelength: 450~490nm | |
Fluorescence filter system G Exciton Wavelength: 495~555nm | |
Fluorescence filter system UV Exciton Wavelength: 320~380nm | |
Fluorescence filter system V Exciton Wavelength: 380~415nm | |
Accessories for VMF30A | ||
|---|---|---|
Eyepiece | WF 16X (Φ11mm) | |
Dividing 10X(Φ20mm) 0.1mm/Div | ||
Objective | Infinity plan achromatic 20X /0.40 | |
Eyepiece Tube | Binocular (inclined 30°) | |
Nosepiece | Quintuple (Backward Ball Bearing inner Locating) | |
Filter | Yellow filte | |
Green filter | ||
Phase Contrast Unit | Eyepiece | Centering Telescope |
Objective | Infinity phase contrast plan achromatic 10X/0.25 PHP | |
Infinity phase contrast plan achromatic 20X/0.40PHP | ||
Infinity phase contrast plan achromatic 40X/0.65 PHP (Spring) | ||
Infinity phase contrast plan achromatic 100X/1.25 PHP (Spring, Oil) | ||
(PH-¢ñ) Turnplate phase contrast condenser | ||
(PH-¢ò) Turnplate phase contrast condenser | ||
Flashboard phase contrast condenser | ||
Pull board phase contrast condenser | ||
CCD Adapter | 0.4X | |
0.5X | ||
1X | ||
0.5X (with dividing 0.1mm/Div) | ||
Camera | With USB & Video Output | |
With USB Output | ||
With Video Output | ||
Digital camera adapter | CANON Digital Camera Adapter (A610, A620, A630, A640) | |
Photograph Unit | 2.5X/4X Change over photograph attachment with 10X viewing eyepiece | |
4X Focusing photograph attachment | ||
MD Adapter | ||
PK Adapter | ||
