Polarizing Microscopes
PLJ-137A 40X~1600X Easy Operation Powder Crystal Trinocular Standard Polarizing Microscope with LED Light Source
- Wide-field plan eyepieces: 10X, field number Ф18mm
- Polarizer, λ, λ/4 compensator
- Analyer, 0°~90°, push in/ out from optical path conveniently
- Coaxial coarse/fine focus system, minimum division of fine focusing: 10μm
- 360° graduated in 1° increments, rotatable working stage, Φ160mm, minimun vernier division: 6’
POL2600 Trinocular Standard Polarizing Microscope with Strain-free Achromatic Objective
- Transmitted illumination system
- Equipped with strain-free plan objectives (center adjustable) and wide field eyepiece
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener stage vertical effective movement up to 30mm
POL1100 Series Polarizing Microscope with Transmitted Halogen Lamp & Abbe Condenser
- Equipped with achromatic objectives and wide field eyepiece
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm
- Rotatable stage, diameter 120mm/ Duoble layer mechanical stage, size: 135mm x 125mm
- Abbe Condenser N.A. 1.25, Rack & Pinion adjustable
POL1520 Trinocular Standard Polarizing Microscope with Reflected & Transmitted Halogen Lamp
- Reflected & Transmitted illumination system
- Equipped with strain-free plan objectives (center adjustable) and wide field eyepiece
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener stage vertical effective movement up to 30mm
POL1510 Trinocular Standard Polarizing Microscope with Reflected Halogen Lamp
- Reflected illumination system
- Equipped with strain-free plan objectives (center adjustable) and wide field eyepiece
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener stage vertical effective movement up to 30mm]
POL1500 Trinocular Standard Polarizing Microscope with Transmitted Halogen Lamp
- Transmitted illumination system
- Equipped with strain-free plan objectives (center adjustable) and wide field eyepiece
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener stage vertical effective movement up to 30mm
POL1600 Series Trinocular Standard Polarizing Microscope with Transmitted Halogen Lamp
- Wide-field plan eyepieces: field number Ф18mm.
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Take-down style polarizer, 360° rotatable, have 0, 90, 180, 270 four scale, located down the aperture diaphragm
- Impellent style analyer, 360° rotatable, push in/ out from optical path conveniently
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener
POL1800 Trinocular Birefringence Object Research & Identification Polarizing Microscope
- Adopt infinity optical system
- Infinity long W.D plan objectives, the field of view is widely and clear.
- Wide-field plan eyepieces: field number Ф22mm.
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Take-down style polarizer, 360° rotatable, have 0, 90, 180, 270 four scale, located down the aperture diaphragm
- Impellent style analyer, 360° rotatable, push in/ out from optical path conveniently
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener
- Wide voltage range power supply (85-265V 50/60Hz), 6V30W halogen lamp, brightness adjustable.
- Trinocular can be observation for eyepieces and microphotography in 100% light flux, suits for low illuminance microphotography.
POL1810 Trinocular Scentific Research Reflected & Transmitted Polarizing Microscope
- Adopt infinity optical system and modularization function design
- Infinity long W.D plan objectives, the field of view is widely and clear.
- Wide-field plan eyepieces: field number Ф22mm.
- Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
- Polarizing unit can be move out or into optical path, polarizer and analyzer can be rotated from 0°to 360°
- Rotatable stage, 360° graduated in 1° increments, minimum retardation resolution 6' center adjustable and with tightener Stage vertical effective movement up to 30mm.
- Wide voltage range power supply (85-265V 50/60Hz), 6V30W halogen lamp, brightness adjustable.
- Trinocular can be observation for eyepieces and microphotography in 100% light flux, suits for low illuminance microphotography
