4X~100X Watch Repair Phone Binocular Stereo Microscope with 360° Rotatable Head
6.3X; 25X Eyepiece; 4X~100X Mag.; Phone Microscope; Stereo Microscope
Features
- 6.3X; 25X Eyepiece
- 0.64X,1X,1.6X,2.5X,4X Objectives
- Binocular 360° Rotatable Head
- Connect with Microscope Camera Available
Tags: Stereo MicroscopesIndustrial Inspection
Request a Quote?
Get Quote Live chat Email Phone
6.3X~25X
2mm~44mm
100mm
XTT-100 binocular graded zoom stereo microscope has the advantages of simple operation, convenient use, clear imaging and high cost performance. It could be used for teaching demonstration, biological anatomy and observation and analysis by public security departments, also for precision parts assembly and inspection in electronic industry and seed inspection in agriculture. Total magnification: 4X-100X.
XTT -100 Stereo Microscope
XTT-100 Stereo Microscope
XTT-100 Stereo Microscope
Eyepiece & Rotatable Head of XTT-100 Stereo Microscope
Focusing Knob & Magnification Adjustable of XTT-100 Stereo Microscope
Specification for XTT-100: | ||||||
|---|---|---|---|---|---|---|
Eyepiece | 6.3X; 25X | |||||
Magnification | 6.3X: | 4X | 6.3X | 10X | 16X | 25X |
25X: | 16X | 25X | 40X | 63X | 100X | |
Field of View(mm) | 6.3X: | 44 | 28 | 17.5 | 11 | 7 |
25X: | 12.5 | 8 | 5 | 3 | 2 | |
Total Magnification | 4X~100X | |||||
Head | Binocular 45° inclined, Interpupillary distance:55~75mm | |||||
Working Distance | 100mm | |||||
Diopter | ±5 | |||||
Focusing Range | 50mm | |||||
Pole Length | 110mm | |||||
Objective Aperture | 39mm | |||||
Working Stage | ∅95mm | |||||
Dimension | 15 x 21 x 35cm; Package: 20 x 25 x 40cm | |||||
Weight | Net: 4.4Kg; Gross: 5.2Kg | |||||
Standard Packing List for XTT-100: | |
|---|---|
A | Main Microscope |
B | 6.3X Eyepiece |
C | 25X Eyepiece |
D | B/W Working Stage |
E | Eye guard |
F | Dustcover |
G | Operation Manual |
Optional Accessory for XTT-100: | ||
|---|---|---|
H | Eyepiece | WF20X |
I | Auxiliary Objective | 0.5X, 0.3X, 2X |
J | Illumination | LED Ring Light, Fiber Cold Light, Fluorescent Light |
K | Moving Stage | X-Y: 70*50mm |
L | Microscope Camera | 5MP, 9MP, 10MP, 12MP, 20MP CMOS Sensor USB3.0 Camera |
